Double Glazed Units Specification
We use a variety of different double glazed units to suit the individual specification for our sash windows. We can make windows to suit any thickness of double glazed units, however an overall thickness of around 18mm is about the maximum you can fit before it starts to look a lot thicker than a traditional sash and case window.
For double glazed sashes in listed buildings and conservation areas, a slimline unit is often stipulated. This would normally be a 14mm, 4/6/4, argon filled, low e glass unit. We would usually fit toughened glass to the lower sashes for safety reasons for no additional cost .
We have adjusted the profiles of our sashes to allow us the maximum detail possible to the timber moulding, as well as the maximum energy efficiency. Sash and case windows are a traditional design and it has always been our company’s aim to keep them as traditional looking as possible.
Our windows are manufactured with haunched tenons to allow for the additional weight in a double glazed unit and often our top sashes have an ornate horned detail. The horn on the upper sash is a traditional detail to give strength to the upper sash in large windows (see picture to right).
To the eye our windows match almost exactly the look of the original single glazed sash.
Comments are closed.
One of the above is Double Glazed - Which one? The window on the right is a 14mm slim line double glazed unit with a 27mm astrical. Split down the middle into a
2 over 2 with a 'through' astrigal making four individual double glazed units.
